Mass Spectrometer Filament Assembly

  We are pleased to introduce our new product, Filament Assembly supports , which is a drop-in replacement filament for ion trap mass spectrometers. Direct replacement for products offered by Thermo, Varian, Perkin-Elmer, Teledyne, and Hitachi. Customers can choose from two-pin and four-pin options, tensioned and aligned to maximize mass spectrometer performance. These filament assemblies are manufactured from our alumina ceramic, chosen for its good electrical insulation and high temperature stability. Innovacera’s brazing process makes the filament more resistant to temperatures of around 700 ° C, compared to standard adhesives that typically can only withstand temperatures up to 350 ° C. Welding method Ceramic to Metal Brazing (or Soldering) Glass to Metal Sealing If you are interested, please contact us. Our experienced team of engineers will select the appropriate brazing fixture, joint design, and process for your application.

99% Alumina Laser pumping cavity ceramic reflector

The material of the ceramic reflector is   99% Al2O3 . Its green body is fired at a suitable temperature to retain the proper porosity and strength. The surface of the ceramic reflector is coated with a high-reflectivity ceramic glaze, so it has a longer service life and a more diffuse reflection compared to the gold-plated reflector. Production Process Preparation of the green body Preparation of glaze slurry: raw material weighing, grinding, sand screening Glazing: glazing by spraying Glaze burning: The glazed product is burning at a high temperature Inspection: Appearance inspection, dimensional measurement, and reflectance measurement Packaging Prime Features Surfaces can be sealed and coated with a solarization-resistant glaze to give high bulk reflectivity 97% reflectance efficiency at 600-1000nm Reflectance efficiency exceeds 95% across the wavelength range 400-1200nm (see curve) Controlled porosity Good thermal conductivity High electrical resistivity Precautions for the u...

Alumina Ceramic Metallization Disc with 3 Holes for TO Package

  Alumina ceramic metallization discs , designed with 3 holes, were typically used in TO (Transistor Outline) packages. Providing the hermetic sealing, electrical insulation, and thermal stability in strict conditions for high-reliability electronic packaging.     Product Overview Alumina ceramic metallization is the process of applying molybdenum-manganese (Mo-Mn), then coating with Nickel on ceramics, bonding both the mechanical and electrical properties of ceramics and metals together. These three through-holes are to accommodate metal feedthrough pins, allowing for electrical interconnection while maintaining hermetic isolation. The metallized alumina disc forms the insulation base for TO packages like TO-3, TO-5, TO-8, TO-39, etc.   Application Areas -TO Packages (e.g., TO-3, TO-5, TO-8, TO-39) -Power semiconductor devices -Laser diodes and optoelectronic packaging -RF and microwave device packaging -High-reliability and hermetically sealed sensors -Telecommunic...

Intermetallic (BN-TiB2) E-Beam Crucibles Evaporator Boat for E-Beam Sources

  Innovacera can provide a range of crucibles for electron guns, which can also be designed and customized to meet specific needs. May I know if you have chosen the most suitable crucible for aluminum plating? This article explains in detail how to choose it. Let’s go down.     Aluminum will form alloys with tungsten crucibles, molybdenum crucibles, and tantalum crucibles, which cause corrosion on the inside of the crucible and also contaminate aluminum. At the same time, the film layer has been contaminated, such as the film being black, dark, and even spotted. Aluminum will also form yellow aluminum carbide with carbon in graphite crucibles, and the formed aluminum carbide will evaporate onto the sample, causing the film to turn yellow. The use of boron nitride crucibles, alumina crucibles, or quartz crucibles is prone to electron beam defocusing issues. The main reason is that the crucible is not conductive, and the excess electrons in the crucible accumulate, resultin...

Micro D Connectors Unveiled: Why They Matter in Today’s Technology

  In the ever-evolving world of electronics, the demand for miniaturized, high-performance connectors is more prominent than ever. One such innovation that has captured the attention of engineers and designers alike is the   Micro-D connector . Known for its compact size and robust design, this connector has become a staple in various industries, including aerospace, defense, and telecommunications.   Understanding Micro D Connectors Micro D Connectors are small, rectangular connectors designed to offer high-density connectivity in a compact footprint. Despite their miniature size, these connectors are engineered to provide reliable electrical connections, even in the most demanding environments. With their ability to accommodate multiple pins in a confined space, Micro D Connectors are ideal for applications where space is at a premium, but performance cannot be compromised.   The Role of Glass-to-Metal Seals One of the key components that contributes to the reliabi...

Alumina Ceramic Focus Rings

Alumina Ceramic Focus rings are designed to improve etch uniformity around the wafer edge or perimeter. When used with an electrostatic chuck (e-chuck), the wafer rests on the edge focus ring – held in place by the electrostatic charge. Alumina Ceramic Focus Rings serve as critical components within plasma etch equi pment, primarily in the etch chamber. The rings are strategically positioned to optimize plasma distribution and maintain uniformity during the etching process. Semiconductor manufacturing processes require operation within cleanroom environments, particularly for components used under high-temperature, vacuum, and corrosive gas conditions. Ceramic materials maintain high stability within these complex physical and chemical environments. The Ceramic Focus Ring is a critical part of the Semiconductor Etch Process. When aluminum alloy is chosen as the etch chamber material, it can easily cause metal particle contamination. Therefore, high-purity (over 99.5%) alumina ceramic ...

Aluminum Nitride Ceramic Part Typical Applications

  Compared with other ceramic materials,   AlN   has a thermal expansion coefficient that matches silicon and excellent thermal conductivity, which makes it more suitable for use in the electronics industry.   Aluminium Nitride Ceramic   Material Properties is as bleolw. Aluminum nitride can also be used in heat exchangers, crucibles, protective tubes, casting molds, piezoelectric ceramics and films, thermally conductive fillers, etc. Below is some application of  Aluminum nitride ceramic components . 1. Heat dissipation substrate and electronic device packaging Heat dissipation substrates and electronic device packaging are the main applications of AlN ceramics. Aluminum nitride ceramics have excellent thermal conductivity, thermal expansion coefficient close to silicon, high mechanical strength, good chemical stability, and are environmentally friendly and non-toxic. It is considered an ideal material for a new generation of heat dissipation substrates an...

Aluminum Nitride Applications & Features Is Outstanding And Demand Is Growing

  Aluminum nitride   is a covalently bonded compound with a hexagonal brazingite structure. Aluminum nitride has a series of excellent features as below: Excellent thermal conductivity, Reliable electrical insulation, Low dielectric constant, Dielectric loss, Non-toxic, Has a thermal expansion coefficient that matches silicon. Aluminum nitride has become a material of great concern in the electronics field due to its excellent thermal conductivity and thermal expansion coefficient matching that of silicon. ALN material is not only an ideal material for new generation heat dissipation substrates and electronic device packaging, but also can be used in heat exchangers, piezoelectric ceramics and films, thermal conductive fillers, etc., with broad application prospects. The crystal structure of AlN determines its excellent thermal conductivity and insulation properties. According to the study “Research on Tape Casting and Sintered Body Properties of  Aluminum Nitride Ceramic...

The introduction of quadrupole mass analyzer

  The quadrupole mass analyzer functions as a mass filter by selecting ions with a specific m/z (mass-to-charge ratio) value for analysis. Although quadrupole mass spectrometers do not match sector magnetic field instruments in sensitivity, resolution, or upper mass range, they dominate clinical laboratories. This is due to their ease of use, relatively low cost, compact size, and straightforward interfacing with gas chromatography (GC) or liquid chromatography (LC) systems.   Figure 1. Schematic diagram of quadrupole mass analyzer   Principle: The quadrupole mass analyzer consists of four parallel cylindrical rods with hyperbolic cross-sections. These rods are charged by direct current and alternating voltage to affect the movement of ions, and the charging method is: the two diagonal rods have the same voltage, while the two vertical rods have voltages of opposite signs.   Figure 2. Main view of quadrupole mass analyzer   Ions must slowly enter the quadrupole ...

Anti-static Ceramic Tweezers-Stainless Steel Handle With Ceramic Tips

  Ceramic Tweezers: Ideal for Precision Operations With its unique material properties and functional design, ceramic tweezers have become the new favorite precision tool in laboratory, electronic manufacturing, medical cosmetology and other fields.     Material Characteristics: Technology Enables Quality Anti-static Ceramic tweezers are made of zirconia ceramics, wear-resistant and scratch-resistant, tweezers are easy to maneuver. The material is insulating and safe for use in electrically charged environments; it is also resistant to high temperatures, acid and alkali corrosion, and has stable performance in chemical environments, avoiding the risk of metal contamination.   Functional Advantage: Combination of Precision and Safety Conventional metal tweezers are prone to conductivity/magnetization problems, while ceramic heat resistant tweezers are insulated and anti-static, safe for clamping precision electronic components (e.g. chips, wafers) and protecting sensi...
